Hmm... I'm sure I have seen such a diagram, but I can't remember where!
Some terms:
- Cockpit: the part of the boat that you sit in, including both the area where your bum goes and where your feet rest.
- Bucket, Seat - the part of the cockpit that your bum sits in.
- Footwell: the forward part of the cockpit where your feet go.
- Footplate: the flat board that your feet rest on.
- Foot pedals/rudder pedals: the pedals that the tops of your feet press on to activate the rudder.
- Nose/bow: the front-most part of the ski
- Tail/stern: the rear-most part of the ski
- Rails: the top edges of the cockpit.
- Rocker: the amount of curve in the bottom of the ski. A ski that has a lot of rocker looks like a banana; a ski that has little rocker looks much flatter. Skis with plenty of rocker catch waves more easily but are slower on flat water (as a general rule).
- Runner/Run: A wave on the open ocean that can be surfed. The Aussies call them runners, South Africans call them runs.
- Downwinder/downwind: a paddle where you're going with the wind, surfing the waves. Aussies call them downwinders, Saffas call them downwinds!
- Wave deflector: A small shield taped to the front deck in front of the cockpit that deflects water coming over the nose of the ski and helps prevent the cockpit from being flooded.
- leash: made from rope or coiled plastic with a padded, velcro fastening on end that typically goes around a paddlers ankle and a rope loop on the other end that generally goes through an anchor point on the bottom of the cockpit. Prevents the paddler from losing the ski when they fall off in windy conditions.
